5 - 16 Adjustments / Programs
Save values and end adjustment 5
• In the "Available Functions:" window select "INIT OFF & STORE VALUES" and click on
"Execute".
• Close the status window by clicking on the OK button.
• For the query "Do you want to reset the unit", click on "Yes".
Concluding tasks 5
Before ending the service program, save the new parameter values to disk
(Service PC, Data menu, Backup).
Slot diaphragm 5
Prerequisites
• The setting of the camera rotation is correctly adjusted and is in the 0° position.
• Mark the circle mask diameter in the upper left corner and lower right corner on the
screen of monitor A.
• Connect the service PC to the serial interface of the SIREMOBIL.
• Start the service program.
• Select the "Adjustments, Calibrations..." menu. Answer the query with "Yes".
• Select "SCREEN DISPLAY SLOT DIAPHRAGM" in the "Function Groups:" combo box.
Disable circle mask 5
• Switch off zoom.
• In the "Available Functions:" window, select "DISABLE CIRCLE MASK" and click on "Ex-
ecute". Close the status window by clicking on the OK button.
For the query "Do you want to reset the Unit", click on "No".
Start adjustment 5
• In the "Available Functions:" window select "INIT" and click on "Execute". Close the sta-
tus window by clicking on the OK button.
For the query "Do you want to reset the Unit", click on "No".
Full format, slot diaphragm open 5
• Move the camera into the 0 degree position. The X-Iris opens to survey format. To open
it farther, use the keys for opening the X-Iris.
The slot diaphragm is opened automatically.
• Apply fluoro briefly.
• Open and close the slot diaphragm display via the keys.
• Align the lines shown on the monitor with the front edges of the slot diaphragm blades.
Use the lowest KV values possible to ensure optimal detection of
the front edges of the slot diaphragm blades.
NOTE
