MEMOSKOP C / MEMOSKOP C & MOD 6
• Replace the MEMOSKOP .
The attachment screws are accessible on the underside of the storage device.
• Check the software status of the MEMOSKOP. Download the system software to the
MEMOSKOP if necessary.
• Use the MEMOSKOP Service Software to import the language file.
• Set the MEMOSKOP C to the correct video frequency and configure it for the number of
existing monitors.
Refer to chapter 5 "Configuring the video frequency " and "MEMOSKOP - Configuration
for the number of existing monitors ."
• Configure the following parameters in Technical Setup for MEMOSKOP:
Check the software status of the newly delivered MEMOSKOP.
If the software status of the MEMOSKOP differs from that of the
system, the system software status must be downloaded to the
MEMOSKOP.
The MEMOSKOP software status can be read out in the 2nd line
of the User Setup.
The first number describes the MEMOSKOP type.
(2=CE; 3= CE-100/ C/ C & MOD; 4=C-SUB/ C-SUB & MOD).
Read and record the parameters for MEMOSKOP if you can select
User setup. After replacing the MEMOSKOP, configure the
MEMOSKOP according to the parameters noted.
Number of Monitors Configure 1 for SIREMOBIL with 1 monitor.
Configure 2 for SIREMOBIL with 2 monitors.
Hardcopy Check whether 5000 is programmed in "4 Max Hardcopy
time". If not, program this value.
Edge 1 coef set Check whether 3 is programmed, If not, program this value.
Edge 2 coef set Check whether 8 is programmed, If not, program this value.
Motion detection setup Check whether the following are programmed "MD1:
Threshold" 100 and for "MD2: Threshold" 120. If not, pro-
gram these values.
Date / Time format Set the country-specific format.
Keyboard Set to the keyboard layout being used.
Language Set for language of the country.
Display of realtime clock Configure Yes. Select No only upon customer request.
Display of rotated images Configure Yes.
Monitor zoom Configure No.
Monitor split Configure Yes.
Monitor text Configure Yes.
Maximum image number Configure 700.
