Siemens SIREMOBIL Iso-C

SIREMOBIL Iso-C SPR2-230.061.01 Page 6 of 48 Siemens AG
System Manual Rev. 13 12.04 CS PS 24 Medical Solutions
6 - 6 Replacing boards / replacing components
Power Supply M14, +5 V / +15 V / -15 V 6
• Replace the power supply.
• Check the power supply voltage and, if necessary, adjust it. Refer to chapter 3 of these
instructions, Checking the operating voltages.
Power Supply M13, +13 V VIDEOMED DC 6
• Remove the Plexiglas cover over the power supply. Remove the 4 Allen screws.
• Replace the power supply.
• Check the power supply voltage and , if necessary, adjust it. Refer to chapter 3 of these
instructions, Checking the operating voltages.
Electrical voltage!
See Chapter 1, Safety Information.
Switch system power supply off and disconnect the power plug.
Electrical voltage!
See Chapter 1, Safety Information.
Switch system power supply off and disconnect the power plug.
WARNING
WARNING
