Siemens SIREMOBIL Iso-C

Adjustments / Programs 5 - 13
Siemens AG SPR2-230.061.01 Page 13 of 30 SIREMOBIL Iso-C
Medical Solutions Rev. 13 12.04 CS PS 24 System Manual
• The mechanical limits are checked and the position values are automatically stored.
• Camera rotation is automatically moved to the 0 degree position.
• The X-Iris is opened to max.aperture.
• Switch off Zoom .
• Attach a centering cross or equivalent object to the I.I. for evaluating the position of the
fluoro image.
• Switch on fluoro and move the slot diaphragm to the 0 degree position using the keys for
rotating the slot diaphragm. The blades should be in the vertical on the monitor screen.
• Switch off fluoro.
• In the window "Available Functions:" select "0 DEGREE POSITION" and click "Execute".
• Close the status window by clicking on the OK button.
• Respond to the query "Do you want to reset the unit" by clicking "No" .
• Switch on fluoro.
• Open the slot diaphragm to where the blades begin to disappear at the edge of the im-
age.
• Switch off fluoro.
• In the window "Available Functions:" select "FULL FORMAT POSITION" and click "Exe-
cute".
• Close the status window by clicking on the OK button.
• Respond to the query "Do you want to reset the unit" by clicking "No".
• Select the zoom format.
• Switch on fluoro.
• Open the slot diaphragm to where the blades begin to disappear at the edge of the im-
age.
• Switch off fluoro.
• In the window "Available Functions:" select "ZOOM FORMAT POSITION" and click "Ex-
ecute".
• Close the status window by clicking on the OK button.
• Respond to the query "Do you want to reset the unit" by clicking "No" .
• In the window "Available Functions:" select "Enable circle mask" and click "Execute"
• Respond to the query "Do you want to reset the unit" by clicking "No" .
• In the window "Available Functions:" select "INIT OFF & STORE POSITION" and click
"Execute".
• Close the status window by clicking on the OK button.
• Respond to the query "Do you want to reset the unit" by clicking "Yes". The adjustment
values are stored.
X-ray radiation!
See Chapter 1, Safety Information.
Observe the need for radiation protection. Wear a lead apron.
WARNING
