5 - 20 Adjustments / Programs
• Connect the service PC to the serial interface of the SIREMOBIL Iso-C.
• Start the service program.
• Select the Adjustment, Calibrations menu.
• Answer the query "yes".
• In the Combo box "Function Groups:" select "Camera Rotation".
• In the window "Available Functions:" select "1. Init (Disable Limits)" and click on "Exe-
cute".
• For the query "Do you want to reset the Unit", click "No".
• Attach the center cross or equivalent to the image intensifier.
• Start fluoro and rotate the camera to the +180° position (With the camera rotation key
clockwise). The image contents should rotate counterclockwise.
• Stop fluoro, in the window "Available Functions:" select "2. +180 Degree Position" and
click on "Execute".
• For the query "Do you want to reset the Unit", click "No".
• Start fluoro and set camera rotation to the 0° position. The image (left/right / up/down)
corresponds to Fig. 3.
• Stop fluoro, in the window "Available Functions:", select "3. 0 Degree Position" and click
on "Execute" .
• For the query "Do you want to reset the Unit", click "No".
• Start fluoro and rotate the camera to the -180° position (with the counterclockwise cam-
era rotation key ). The image contents will rotate clockwise.
• Stop fluoro, in the window "Available Functions:", select "4. -180 Degree Position" and
click on "Execute" .
• For the query "Do you want to reset the Unit", click "No".
• In the window "Available Functions:" , select "5. Init Off & Store Positions" and click on
"Execute".
• For the query "Do you want to reset the Unit" , click "Yes".
• Return to the service program main menu with the ESC key.
• Select the Data, Backup... menu.
• Select Parameter in the Backup window.
• Click on "Backup".
• In "Remarks for Parameter" , enter "camera rotation set".
• Click "OK". The new position values for camera rotation will be stored to the disk.
• Switch the SIREMOBIL Iso-C OFF and ON again.
• Check the adjustments again. In the 0° position, the object image must correspond to the
one in Fig. 3.
