SIGLENT
80 SDS2000X User Manual
trigger type is set to serial.
(Tip: The SDA should be stable during the whole high clock cycle, otherwise it will be
interpreted as a start or stop condition (data transitioning while the clock is high).)
7. Press softkey to return previous menu.
8. Press Address softkey and select the length of the IIC signal address (7 bits or 10
bits).
