Universal Knob
1. Adjust the waveform intensity
When the menus are hidden, you can use the waveform intensity knob to adjust
waveform intensity (0% ~ 100%). Turn clockwise to increase the brightness and
counterclockwise to reduce. You can also press Display/Persist→Intensity and
use the knob to adjust the intensity. To adjust grid brightness (0% ~ 100%)or
transparency (20% ~ 80%), please operate in the same way as waveform intensity.
2. Universal Knob
In menu operation, the light below the knob is illuminated. In such cases, the knob can
be used to select between submenus under the current menu. Press the knob to
select the current submenu. In addition, it can be used to modify parameters and to
input a file name.
