10 SDS2000X User Manual
The Front Panel
Figure 6: Front Panel Overview
NO.
Description
NO.
Description
1
Horizontal Control
13
Function Menus
2
Auto Setup
14
WaveGen Control
3
Run/Stop
15
Vertical Control for Analog Channels
4
Default Setup
16
WaveGen Output
5
Clear Sweeps
17
Probe Compensation/ Ground
Terminal
6
Universal Knob
18
USB Host
7
Trigger Control
19
Digital Inputs
8
Decode Control
20
Analog Inputs
9
Digital Channel Control
21
One- Button shortcut for Save
10
Math Function
22
Function Menu Softkeys
11
Reference Function
23
Power On/Off
12
Vertical Control for Math and Ref
