SDS2000X User Manual 5

To Connect to Power Supply

The oscilloscope will accept a 100~240V, 50/60Hz or 100~120V, 400Hz power supply.

Please use the power cord provided with the accessories to connect the instrument to the

power source as shown in the figure below.

Figure 4: To Connect to Power Supply

Power

socket
