SDS2000X User Manual 167
I/O Set
SDS2000X provides abundant I/O interfaces, including: USB Device, LAN and Aux
Output.
To Set the USB Device
Do the following steps to set the oscilloscope to communicate with PC via USB:
1. Install the USBTMC device driver on PC. The latest compatible version of National
Instruments VISA is suggested.
2. Connect the oscilloscope with the PC using a standard USB cable
3. Press the Utility button on the front panel to enter the UTILITY function menu.
4. Press the I/O Set softkey to enter the I/O SET function menu.
5. Press the USB Device softkey to select USBTMC.
6. Use EasyScopeX or NI-MAXto communicate with the oscilloscope.
Do the following steps to set the oscilloscope to print the screen image:
1. Connect the oscilloscope with print using a standard USB cable.
2. Press the Utility button on the front panel to enter the UTILITY function menu.
3. Press the I/O Set softkey to enter the I/O SET function menu.
4. Press the USB Device softkey to select Printer.
5. Press the Print button on the front panel to print the screen image.
