Units for Math Waveforms
Use the channel function menu to set the unit of each channel to ―V‖ or ―A‖. SDS2000X
math operation includes units as below:
Math Operation
Unit
Addition (+)or subtraction (-)
V, A
multiplication (*)
V
∧
2, A
∧
2 or W (Volt-Amp)
division (/)
None or S
FFT
dBVrms, Vrms, dBArms, Arms, dBm
differential (d/dt)
V/S or A/S (V/second or A/second)
integral (∫dt)
VS or AS (V/second or A/second)
square root (√)
V
∧
1/2 or A
∧
1/2
