External save and recall
Before using external storage and recall, make sure that the USB flash device is
connected correctly. External storage supports all available file types. The oscilloscope
cannot recall/save Picture or CSV file types.
 Save the specified type of file to the external USB flash device.
1. Press the Save/Recall button on the front panel to enter the SAVE/RECALL
function menu.
2. Press the Save softkey to enter the SAVE function menu
3. Press the Type softkey to select Waveforms or Setup
4. Press the Recall softkey to enter the SAVE/RECALL file system.
Figure 87: SAVE/RECALL File System
5. Use the Universal Knob to select the desired location. File can be stored under
the root directory or in a certain folder under the root directory of the USB storage
device.
