SIGLENT

SDS2000X User Manual 125

FFT Operation

FFT is used to compute the fast Fourier transform using analog input channels or

reference waveforms. FFT takes the digitized time record of the specified source and

transforms it to the frequency domain. When the FFT function is selected, the FFT

spectrum is plotted on the oscilloscope display as magnitude in dBV versus frequency.

The readout for the horizontal axis changes from time to frequency (Hertz) and the vertical

readout changes from volts to dB.

FFT operation can facilitate the following works:

 Measure harmonic components and distortion in the device-under-test

 Measure the characteristics of the noise in DC power

 Analyze vibration
