SDS2000X User Manual 213

Default Setup

Press the Default button on the front panel to set the SDS2000X back to the factory

default values as shown below:

Horizontal

T/div

1μs/div

Delay

0 S

Zoom

Off

Format

Y-T

Vertical

Channel on/off

CH1

V/div

1 V/div

Offset

0 V

Coupling

BW Limit

Full

Adjust

Coarse

Probe

Impedance

1 MΩ

Unit

Invert

Off

Acquire

Acquisition

Normal

Sinx/x

Mem Depth

14 Mpts

Trigger

Type

Edge

Source

CH1

Slope

Rising

Holdoff

Off

Coupling

Noise Reject

Off

Mode

Auto

Display

Type

Vectors

Color

Off
