118 SDS2000X User Manual
To Save Reference Waveform
SDS2000X can save analog channel or math waveforms to one of four reference
waveform locations in the oscilloscope internal memory. Then, a reference waveform can
be displayed and compared against other waveforms. Four reference waveforms can be
displayed at a time.
Use the appointed Variable knob and the Position knob which on the right side of the front
panel to adjust the vertical scale and the vertical position of REF waveform.
The contents of this chapter:
 To Save REF Waveform to Internal Memory
 To Display REF Waveform
 To Adjust REF Waveform Display
 To Clear REF Waveform Display
