To Clear Measurement Parameters
Press the Clear softkey to clear all the measurement parameters that are displayed on the
screen.
To Make All Measurement
All measurements can measure all the voltage, time and delay parameters of the current
measurement source. The table of results will be displayed on the screen.
Figure 80: All Parameters Measurement
Do the following steps to activate the All Parameters display:
1. Press the Measure button on the front panel to enter the MEASURE function menu.
2. Press the All Measure softkey to select On.
3. Press the Source softkey to select the measure source (CH1~4, MATH, REFA,
REFB, REFC, REFD).
