To Connect the Probe

SIGLENT provides passive probes for the SDS2000X series oscilloscopes. For detailed

technical information of the probes, please refer to the corresponding Probe User‘s Guide.

Connect the Probe:

1. Connect the BNC terminal of the probe to one of the channel BNC connectors on the

front panel.

2. Connect the probe tip to the circuit point under test and the ground alligator clip of the

probe to the ground terminal of the circuit.
