Interpreting UART/RS232 Decode
The frames of decoding result:
 RX— The decoding result of the data received.
 TX— The decoding result of the data transmitted.
The lists of decoding result:
 NO — The number of frames in screen.
 TIME(timestamp) — The horizontal displacement between current frame and trigger
position.
 RX — The receiving channel.
 TX — The transmitting channel.
 RX ERR— Parity error or unknown error in the data received.
 TX ERR— Parity error or unknown error in the data transmitted.
