SIGLENT

206 SDS2000X User Manual

enough time to wait for the entire acquisition.

4. Press the softkey to replay the waveform from the current frame to 1.

5. Press the softkey to stop replay.

6. Press the softkey to replay the waveform from the current frame to the last

frame.
