SDS2000X User Manual 209
Offset/Offset Fine/ Low-Level/
Low-Level-Fine/ Width/ Width
Fine value.
DC
Use the Universal Knob to
adjust the Offset value.
± 3.0V
Noise
Use the Universal Knob to
adjust the Stdev/ Mean value.
Cardiac
Use the Universal Knob to
adjust the Frequency/ Frequency
Fine/ Period/ Period /Fine/
Amplitude/ Amplitude Fine/
High-Level/ High-Level-Fine/
Offset/Offset Fine/ Low-Level/
Low-Level-Fine value.
1uHz~5MHz
4mV~6V
± 3.0V
Gauss
Pulse
Use the Universal Knob to
adjust the Frequency/ Frequency
Fine/ Period/ Period /Fine/
Amplitude/ Amplitude Fine/
High-Level/ High-Level-Fine/
Offset/Offset Fine/ Low-Level/
Low-Level-Fine value.
1uHz~5MHz
4mV~6V
± 3.0V
Exp
Rise
Use the Universal Knob to
adjust the Frequency/ Frequency
Fine/ Period/ Period /Fine/
Amplitude/ Amplitude Fine/
High-Level/ High-Level-Fine/
Offset/Offset Fine/ Low-Level/
Low-Level-Fine value.
1uHz~5MHz
4mV~6V
± 3.0V
Exp
Fall
Use the Universal Knob to
adjust the Frequency/ Frequency
Fine/ Period/ Period /Fine/
Amplitude/ Amplitude Fine/
High-Level/ High-Level-Fine/
Offset/Offset Fine/ Low-Level/
Low-Level-Fine value.
1uHz~5MHz
4mV~6V
± 3.0V
When the Output Load is set to 50Ω, the maximum output level will be reduced by
50%.
