15.2 System LEDs
LED
Color
Description
PWR (Power)
Green – Power OK
Blink Green – Device boot
Red – Power Failure
Off – No Power
RF
Green – Link Up
Blink Green – Device boot
Orange – Alignment Mode
Off – Link Down
ETH1/2/3/4:
Green – Link 1G
Blink Green – 1G activity
Orange – Link 10/100
Blink Orange – 10/100 activity
Off – No Link (Carrier)
15.3 Alarms
System alarms can be found on the Main Page, including:
 Current Alarms – list of currently active alarms and date+time raised.
 History Log – System alarms and events history log
Event Name
Description
Probable Cause
Corrective Actions
Cold start: the first
time wake up
System power up
after power
connection
1) Restoring the power
2) Reset caused by power
disruption
Power restored, no corrective
actions needed
Cold start: software
initiated reset
System power up
after user-
initiated software
reset
1) User action: reset
system
2) User action: rollback
timeout expired
3) User action: SW
upgrade
Power restored after user
action, no corrective actions
needed
Cold start: reset
button has been
pushed for less
than 5 sec
System power up
after user pressed
the reset button
(for less than 5
seconds)
1) User action: reset
button pressed for less
than 5 seconds causing a
reset
Power restored after user
action, no corrective actions
needed
Cold start: reset
button has been
pushed for more
System power up
after user pressed
the reset button
1) User action: reset
button pressed for more
than 5 seconds causing
Power restored after user
action, no corrective actions
needed
