EtherHaul Operation, Administration and Maintenance Manual
Page 84
eth1|eth2|eth3|eth4>] [precedence <1..8>] [vid < list 0..4094>] [pcp <
list 0..7>] [ip-cos <{{dscp-cos | mpls-exp} <list of 0..7>}|dont-care>]
[packet-type < unicast | non-unicast | all] [cos <0..7>]
IP-COS: Priority based on IP header value – DSCP (differentiated services), MPLS-EXP
(MPLS experimental bit), or Don’t-Care (IP header values ignored).
Precedence: Priority between classifiers. Multiple and overlapping classifiers rules may
be configured. In such case, the precedence value will determine the priority between
the overlapping classifier rules. Precedence 1 is the lowest priority.
Default Classifiers Configuration:
set classifier-cos 1 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 0 ip-cos dont-care packet-type all cos 0
set classifier-cos 2 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 1 ip-cos dont-care packet-type all cos 1
set classifier-cos 3 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 2 ip-cos dont-care packet-type all cos 2
set classifier-cos 4 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 3 ip-cos dont-care packet-type all cos 3
set classifier-cos 5 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 4 ip-cos dont-care packet-type all cos 4
set classifier-cos 6 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 5 ip-cos dont-care packet-type all cos 5
set classifier-cos 7 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 6 ip-cos dont-care packet-type all cos 6
set classifier-cos 8 interface host,eth0,eth1,eth2,eth3,eth4 precedence 1
vid 0-4094 pcp 7 ip-cos dont-care packet-type all cos 7
9.8.2 Metering and Coloring
Classifier-evc configuration:
Frames on the ingress are classified onto CoS or EVC (optional)
If no EVC defined, the classifier-cos determines queue number on egress the frame is
forwarded to (CoS)
