EtherHaul Operation, Administration and Maintenance Manual
Page 36
This section allows configuring the following parameters:
 Line Loopback – checkbox to enable loopback on the port. External (towards the
line side) or Internal (towards the radio side) loopback are available, with or
without MAC addresses swap.
Refer to the Diagnostics chapter of this manual for detailed description of the system’s
loopbacks.
 Loopback Timeout – in seconds. Loopback will clear when timeout expires.
5.4 Statistics
Figure 5-4 Eth Ports Page: Statistics
Ethernet performance can be monitored using the advanced statistics counters.
Click View Statistics to review the local and remote Ethernet Performance
Monitoring statistics. Clicking View Statistics will open the Statistics page where all
system’s statistics can be reviewed.
Refer to the Statistics chapter of this manual for detailed description of the system’s
statistics.
5.5 CLI Commands
 Monitoring the Ethernet ports configuration and status:
Show eth
 Changing Ethernet port type from RJ45 to SFP on EH-1200/EH-1200TL systems:
Set eth eth1 ether-type 1000xfd
