9.8 Advanced QoS Configuration
The Web-Based Management GUI supports the commonly-used configuration options.
Advanced QoS Configuration can be configured in CLI only and includes:
 Advanced classification
 Metering (CIR/EIR/CBS/EBS) and Coloring (Ingress QoS color Marking)
 PCP Rewrite
 PFC – Priority-based flow control
 Queue Management
 WRED
9.8.1 Advanced Classification
Classification Criteria combinations:
The EtherHaul supports classification based on combination of the classification criteria
options, such as VID and PCP (or any other combination).
Such combinations are supported on CLI only.
Example:
set classifier-cos 5 interface eth1,eth3,eth4 precedence 1 vid 4
pcp 3 ip-cos dont-care packet-type all cos 4
Classification based on DSCP:
The EtherHaul supports 2 modes of classification based on DSCP: 3 bits (MSB) or 6 bits
(full DSCP). When selecting DSCP (3 Bits), you can combine it with PCP classification (in
addition to VID and MPLS-EXP). When selecting DSCP (6 Bits), you do not have the
option to combine it with PCP classification (in addition to VID and MPLS-EXP).
The availability of classification based on DSCP (3 Bits) or DSCP (6 Bits) is determined per
port in the Eth port configuration in the CLI.
Example:
set eth eth1 classifier-mode
dscp | pcp-dscp
Classifiers Configuration:
Use the following command to configure classifiers (classifier-cos):
set classifier-cos <classifier-id: 1..248> [interface <host|eth0|
