EtherHaul Operation, Administration and Maintenance Manual
Page 25
CINR [dB] – Carrier to Interference + Noise ratio. Indicates the current radio
link’s signal quality. In normal conditions, CINR≥19 indicates a good signal
quality.
Mode – Current operational mode of the link:
o Alignment – Carrier Wave transmission. Used for antenna alignment. No
data over the radio link.
o Static – Fixed modulation profile. If you select Static, you must select from a
list of pre–configured modulation profiles in the Modulation field.
o Adaptive – Adaptive Bandwidth, Code, and Modulation. The system will
work on the highest modulation profile based on the CINR values of the both
sides and will present the current modulation profile.
Estimated Throughput [Mbps] – based on the current modulation profile.
o For FDD systems – value is Full-Duplex.
o For TDD systems – value is aggregated (Half-Duplex).
Current Alarms – list of currently active alarms and date&time raised.
History Log – System alarms and events history log.
User Activity Log – All configuration changes are logged, including user and
date&time (presented in the form of CLI commands).
Actual Layer 1 throughput depends on product's specs. Refer to the EtherHaul
Release Notes for exact specifications.
To view logs, pop-ups must be enabled and allowed on your Internet Browser.
