Robertson AP9 MK3 Autopilot
1-10 20169223D
AP9MKII AUTOPILOT
AP9MKII AUTOPILOT
S9
NFU LEVER
AP9 MK3
REMOTE STATION
EXT. MODE SELECTOR
(OPTION)
F200-40
SEE NOTE
COMMUNICATION LINES
D9X
DISTRIBUTION
UNIT
F200-40
SEE NOTE
EXT. MODE SELECTOR
(OPTION)
S9
NFU LEVER
FU9X
FOLLOW-UP
LEVER
AP9 MK3
MAIN STATION
PWR
NOTE:
WHEN A F200-40 IS
CONNECTED, THE
MODE SELECTOR(S)
MUST INCLUDE AN
"OFF" POSITION.
Fig. 1-7
Dual Station System
