Technical Specifications
20169223D 4-9
4.11 FU91 Steering Lever
Dimensions:............................ See Fig. 4-8.
Protection:...............................IP56
Ambient temperature,........... storage: –25 - +70°C
operation: –10 - +55°C
Safe distance to compass: .....0.3 m
144 (5.67")
68 (2.68")
76 (3.00")
137 (5.40")
144 (5.67")
30 (1.18")
Panel cut-out:138x138 (5.44")
Fig. 4-8
FU91 Steering Lever - Dimensions
