4-2 20169223D
4.2 AP9 MK3 Gyro Interface Board
Input signals: Synchro 1:1
Synchro 90:1
Synchro 360:1
Autopilot excited synchro
Stepper 6 step/deg, 24-70V
4.3 CD109 Course Detector
Dimensions : ....................See Fig. 4-2.
Protection : ....................IP56
Ambient temperature,
storage:......–40 - +85°C
operation: –30 - +60°C
Cable length: ....................1 m
120°
120°
120°
min/max. 80-100 (3.2-4.3")
Ø
6
0
(
2
.
4
"
)
Ø
3
3
(
1
.
3
"
)
35 (1.4")
1000 (39.4")
Fig. 4-2
CD109 Course Detector, dimensions

Simrad Robertson AP9 Mk3 Specifications

General

Brand	Simrad
Model	Robertson AP9 Mk3
Category	Boating Equipment
Language	English
