System description
3
850--164186 A
Figure 1 - SP70 system diagram
Display Monitor
115/230Vac mains
115/230Vac mains
115/230Vac mains
Operating panel
Processor unit
Loudspeaker
Speed log
Course gyro
GPS
Transceiver Unit
Echo sounder
Trawl system
Purse seine system
Hull Unit
230/380/440Vac
3 phase mains
(CD5719 WMF/GIF)
