Menu description
61
850--164186 A
Objects index menu
The Objects index menu is shown in all display modes, and
displays the range (R), bearing (B) and depth (D) to all selected
objects.
Figure 47 - O bjec ts
index menu
The ID abbreviations for the different objects are:
AT - Automatic Target Marker
Ci - Circle Marker
M - Target Marker
OS - Own Ship Marker
PT - Position Track Marker
The number behind the ID abbreviation refers to the same
number on the object in the sonar presentation. The P after the
Automatic Target Track Marker, indicates the priority level where
the audio channel is locked to the target.
When selecting any objects in the list, a submenu with all the
available object data will be shown below the Objects index menu.
When selecting a Target Marker or Automatic Target Track
Marker in the list, a dotted bearing line from the vessel to the
marker will be present.
To delete an object, select the relevant marker in the list, and press
the Delete menu button in the lower part of the menu. Selecting
the Delete All menu button, will delete all objects.
