Range
Range controls are specified as either horizontal or vertical.
Figure 25 -
Range buttons
_
_
+
+
RANGE
Range
H
Range
V
Range
H
Range
V
(CD5352)
HORIZONTAL RANGE
The two upper buttons control the horizontal range. The range
selected is display in the Horizontal index menu and on top of the
tilt indicator in the upper left-hand side of the display.
VERTICAL
RANGE
The two lower buttons control the vertical range. The range
selected is display in the Vertical index menu.
