Menu description
81
850--164186 A
4.9 Warnings and alarms
Message Bar
The Message Bar button is located in the System test index menu
and activates the corresponding submenu.
Figure 65 - Message
Bar submenu
The Message Bar submenu is used for selecting the level on
which the warnings and alarms should be given.
Highlighting ALWAYS ON and then selecting Close activates the
Message bar at the bottom of the display.
Figure 66 - Message Bar
The messages bar presents all warning or error messages issued
by the sonar system.
The bottom message bar displays the most recent message given
by the system, and gives an overview of the number of unread
messages currently in the system. Each of the four messagestatus
fields gives access to an index menu.
→ Warnings, see page 82.
→ Operator alarms, see page 83.
→ System alarms, see page 84.
→ Errors, see pa ge 85.
The message status fields displays in grey when there are no
unread messages. When one or more unread messages exists
Warning and Operational Alarm fields are displayed in yellow,
while System Alarm and Error fields are displayed in red.
