Simrad SP70 User Manual

Simrad SP70
38
850--164186 A
• Position tracking mode: the tilt angle’s centre will
automatically be adjusted with regard to the distance to the
position being tracked. The transducer will tilt automatically
in steps after each transmission.
• Target tracking mode: the tilt angle will automatically be
adjusted to provide the strongest echo within the selected
tracking sector. The upper and lower tilt limits can be used to
prevent tracking surface or bottom echoes.
Note ! If the optional stabilization system i s installed and activated, the
beamformer will automatically adjust the tilt angle with regard to the
vessel’s motion (even if manual tilt is selected). The change in the tilt
angle for the beamformer will not be shown on the tilt indicator.
