Ski-Doo ELITE SERIES User Manual

Section04ENGINE
Subsection 07 (LUBRICATION SYSTEM)
Installation
For installation, reverse the removal procedure.
Pay attention to the following details.
R1503motr288A
2
1
1. Screws M6 x 25
2. Screws M6 x 85
Apply grease on O-rings and rubber rings.
Torque screws to 10 N•m(88lbf•in). Apply Loc-
tite 243 (blue) on threads.
