Section 11 TECHNICAL DATA
Subsection 03 (VEHICLE)
VEHICLE
ELITE SE
DRIVE
Final drive ratio 38/63
Final drive belt deflection mm (in) 11 (.433)
Forward gear ratio 23/31
Reverse gear ratio 17/38
Pitch in 3/8
Chain
Type/links qty/plate qty Silent 46/13
Type TRA IV HD
Clutch engagement RPM 2200 ± 100
Spring color Red/Yellow
Spring length mm (in) 87.9 (3.461)
Weight N.A.
Block N.A.
Cap N.A.
Pin Solid
Ramp 609
Drive pulley
Calibration
Screw position 3
(4)
Type HPV VSA
Spring preload ± 0.7 kg (± 1.5 lb) 7.0 (15.4)Driven pulley
Cam angle 47°/30°
Pulley distance Zmm(in)124.0 ± 0.5 (4.882 ± .020)
Xmm(in)37.0 ± 0.5 (1.457 ± .020)
Offset
Y–X MIN.-MAX. mm (in) 1.5 ± 0.75 (.060 ± .030)
Drive belt part number (P/N) 417 300 207
Drive belt width
(5)
Wear limit mm (in) 34.2 (1.346)
Deflection mm (in) 32 ± 5 (1.260 ± .197)
Drive belt adjustment
Force
(1)
kg (lbf) 11.34 (25)
Width mm (in) 381 (15)
Length mm (in) 3455 (136)
Deflection mm (in) 30 to 35 (1.181 to 1.378)
Track
Adjustment
Force
(2)
kg (lbf) 7.3 (16)
Tra ck SC-10 III
Suspension type
Ski ADSA
Te m pla te 315
