Section10BODY/FRAME
Subsection 01 (BODY)
A34H0OA
REMOVAL OF THE LEFT HAND SIDE PANEL
Installation
For installation, reverse the removal procedure.
WIRING HARNESS
WARNING
Ensure all terminals are properly crimped on
the wires and that all connector housings are
properly fastened. Keep wires away from
any rotating, moving, heating and vibrating
parts. Use proper fastening devices as re-
quired.
CABLES
WARNING
Before installation, ensure that all cables are
in perfect condition. Properly install the cable
ends and secure them in place. Pay attention
to route them properly, away from any rotat-
ing, moving, heating or vibrating parts.
TUBING
WARNING
Always ensure that the fuel and vent lines
are properly fixed to their connectors, that
they are not perforated or kinked and that
they are properly routed away from any rotat-
ing, moving, heating or vibrating parts. Also
check for leaks. Replace if required.
NOTE: Refer to proper Parts Catalog to find suit-
able clip part numbers.
PLASTIC MAINTENANCE
AND REPAIR
MAINTENANCE
Clean the vehicle thoroughly, removing all dirt and
grease accumulation.
To clean use a soft clean cloth and either soapy
water or isopropyl alcohol.
To remove grease, oil or glue use isopropyl alco-
hol.
CAUTION: Do not apply isopropyl alcohol or
acetone directly on decals.
CAUTION: The following products must not be
used to clean or wax any of the plastic compo-
nents used on the vehicles:
– gasoline
– brake fluid
– kerosene
– diesel fuel
– lighter fluid
– varsol
– naphtha
– acetone
– strong detergents
– abrasive cleaners
– waxes containing an abrasive or a cleaning
agent in their formula.
Apply wax on glossy finish only. Protect the ve-
hicle with a cover to prevent dust accumulation
during storage.
