Ski-Doo ELITE SERIES User Manual

Section11TECHNICALDATA
Subsection 02 (ENGINE)
ELITE SE
ENGINE (cont'd)
New nominal 1.1 to 1.3 mm (.043 to .051 in)
Intake
Wear limit 1.6 mm (.063 in)
New nominal 1.25 to 1.55 mm (.049 to .061 in)
Valve seat contact width
Exhaust
Wear limit 1.8 mm (.071 in)
New minimum 20.007 mm (.7876 in)
New maximum 20.020 mm (.7881 in)Rocker arm bore diameter
Wear limit 20.035 mm (.7887 in)
New minimum 19.980 mm (.7866 in)
New maximum 19.993 mm (.7871 in)Rocker arm shaft diameter
Wear limit 19.965 mm (.7860 in)
Cylinder head screw Service limit 148.5 mm (5.846 in)
1
st
Rectangular
2
nd
Taper-facePiston ring type and quantity
3
rd
Oil scraper ring
Rectangular 0.15 mm (.006 in)
Taper-face 0.15 mm (.006 in)
Oil scraper ring
New minimum
0.15 mm (.006 in)
Rectangular 0.3 mm (.012 in)
Taper-face 0.3 mm (.012 in)
Oil scraper ring
New maximum
0.4 mm (.016 in)
Ring end gap
All Wear limit 1.5mm(.06in)
Rectangular 0.025 mm (.001 in)
Taper-face 0.015 mm (.0006 in)
Oil scraper ring
New minimum
0.02 mm (.0008 in)
Rectangular 0.07 mm (.0028 in)
Taper-face 0.06 mm (.0024 in)
Oil scraper ring
New maximum
0.055 mm (.0021 in)
Ring/piston groove
clearance
All Wear limit 0.15 mm (.006 in)
New (minimum) 0.024 - 0.056 mm (.001 - .0022 in)
Piston/cylinder wall clearance
Wear limit 0.1 mm (.0039 in)
Cylinder taper (maximum) 0.03 mm (.0011 in)
Cylinder out of round (maximum) 0.008 mm (.0003 in)
