Section 03 TROUBLESHOOTING
Subsection 03 (ELECTRICAL SYSTEM)
SYMPTOM FALSE FUEL AND/OR TEMPERATURE GAUGE READINGS.
CONDITION NORMAL USE.
1. Verify sender unit for free movement and/or correct arm position.
a. Defective or damaged part.
Correct or replace sender unit.
TEST/INSPECTION
2. Verify sender unit/gauge wiring harness condition.
a. Heating, rotating or sharp part in contact with harness. Improper harness routing.
Replace or repair damaged wires. Reroute where necessary.
SYMPTOM BRAKE LIGHT REMAINS ON.
CONDITION NORMAL USE.
1. Check if bulb is properly installed.
a. Bulb is not installed correctly (contact elements are reversed).
Install bulb correctly.
2. Check brake switch.
a. Switch contact remains closed.
Replace brake switch.
TEST/INSPECTION
3. Check wiring harness.
a. Shortedwiringharness.
Replace or repair wiring harness.
SYMPTOM REAR LIGHT BULB FLASHES.
CONDITION NORMAL USE.
1. Check bulb tightness in housing.
a. Looseness at bulb contact elements.
Install bulb correctly.
2. Check if rear light is properly connected.
a. Connector housing is partially connected.
Install connector housing properly.
TEST/INSPECTION
3. Check continuity of wires.
a. Corroded terminals and/or broken wires.
Replace terminal(s) or crimp defective wires.
SYMPTOM TACHOMETER DOES NOT WORK.
CONDITION NORMAL USE.
TEST/INSPECTION 1. Check continuity of wires.
a. Corroded terminals and/or broken wires.
Replace terminal(s) or crimp defective wires.
