Skyjack SJ12 E - Page 121

121
SJ12 E, SJ16 E, SJ20 E
241914ACA
Display Module Section 5 – Procedures
LOAD CELL - NOMINAL WEIGHT CALIBRATION
CALIBR.LOAD CELL
CALIBRATE LOADED
IS WEIGHT LIFTED
AND PLATF EMPTY?
CALIBR.LOAD CELL
CALIBRATE LOADED
CONFIRM LOADED
CALIBRATE .? XXKG
CALIBR.LOAD CELL
CALIBRATE LOADED
CONFIRM EMPTY
CALIBRAT.? XXKG
CALIBR.LOAD CELL
CALIBRATE LOADED
NOMINAL WEIGHT
SAVING DATA WAIT
CALIBR.LOAD CELL
CALIBRATE EMPTY
PLATFORM EMPTY
CALIBRATION DONE
CALIBRATION
CALIBRATION
CALIBR.LOAD
CELL
CALIBR.LOAD CELL
CALIBRATE LOADED
CALIB.LOAD.CEL:
NOMINAL WEIGHT
CALIBR.LOAD CELL
CALIBRATE EMPTY
IS PLATFORM ISO
LATED FROM BASE?
PLATFORM EMPTY
CALIBR.LOAD CELL
CALIBRATE LOADED
IS PLATF EMPTY
WITHOUT OPTIONS?
CALIBR.LOAD CELL
CALIBRATE LOADED
IS REATED WEIGHT
PUT ON PL? 159KG
Do not cycle machine power
when this window is active
