SJ6826RT, SJ6832RT
213560ABA
Section 3 – System Component Identication and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Qty. Description
33CR 209028 1 RELAY, Power on-demand
34ACR 208882 1 RELAY, 12 Volt 40 Amp (Throttle)
35ACR 209028 1 RELAY, 12 Volt 40 Amp (Throttle enable)
35CR 208882 1 RELAY, 12 Volt 40 Amp (Elevation/High speed cutout)
61CR 209028 1 RELAY, 12 Volt 40 Amp (Outrigger drive enable)
65CR 208882 1 RELAY, 12 Volt (Outrigger lift enable)
86ACR 208882 1 RELAY, 12 Volt 40 Amp (Hydraulic generator stop)
86BCR 208882 1 RELAY, 12 Volt 40 Amp (Hydraulic generator latching)
86CCR 208881 1 RELAY, 12 Volt 40 Amp (Hydraulic generator)
2G-11 208881 1 SOLENOID, Gas shutoff (Kubota Dual Fuel Engine)
B1 208882 1 BATTERY, 12 Volt (Wet)
BP-29 208882 1 BEEPER (7.5 – 16 VDC)
CB1 208881 1 CIRCUIT BREAKER (25 Amp)
CB3 208881 1 CIRCUIT BREAKER (25 Amp)
CM1 158321 1 MODULE, Overload sensing system - ANSI, AS
CM1 139301 1 MODULE, Overload sensing system - CE
CPS1 138224 1 SENSOR, Crankshaft position
CRD1 138225 1 CONTROL CABLE ASSEMBLY (Control console)
CRD2 138226 1 CONTROL CABLE ASSEMBLY (Scissor arm) (Model 6826RT)
144387 1 CONTROL CABLE ASSEMBLY (Scissor arm) (Model 6832RT)
CRD3 137354 1 CONTROL CABLE ASSEMBLY (Electrical panel)
CS-31A 103007 1 SOLENOID, Choke
DXX 102921 AR DIODE
EGP1 KUBOTA 1 PLUG, Engine glow
F1 128595 1 FUSE (300 Amp)
F4 138091 1 FUSE (125 Amp) (Electrical inverter option)
FL-22 121476 1 FLASHING LIGHT
FL-29 103743 1 FLASHER
FP 136119 1 PUMP, Electric fuel
GPL1 133133 1 LIGHT, Glow plug indicator
GPT1 137868 1 TIMER, Glow plug
H1 146652 1 HORN, 12 Volt
HTS-34C 103007 1 SOLENOID, High throttle
ICM1 136121 1 MODULE, Igniter control
IG 137857 1 ALTERNATOR (Kubota Diesel D902)
136101 1 ALTERNATOR (Kubota Dual Fuel WG752)
IGC1 136106 1 COIL, Ignition
IGC2 136106 1 COIL, Ignition
LED-1 137785 1 LIGHT, Power on
LED-2 137785 1 LIGHT, Power on (Base controls)
