SJ6826RT, SJ6832RT
213560ABA
Electrical Parts List Section 3 – System Component Identication and Schematics
Index
No.
Skyjack
Part No.
Qty. Description
LS5 204234 1 LIMIT SWITCH (High drive cutout/tilt override)
LS61 207009 1 LIMIT SWITCH (Front left outrigger up)
LS62 207009 1 LIMIT SWITCH (Front right outrigger retracted)
LS63 207009 1 LIMIT SWITCH (Rear right outrigger retracted)
LS64 207009 1 LIMIT SWITCH (Rear left outrigger retracted)
LS65 207008 1 LIMIT SWITCH (Front left outrigger extended)
LS66 207008 1 LIMIT SWITCH (Front right outrigger extended
LS67 207008 1 LIMIT SWITCH (Rear right outrigger extended)
LS68 207008 1 LIMIT SWITCH (Rear left outrigger extended)
OCM1 132804 1 MODULE, Outrigger auto-level control
OPS1 102838 1 SWITCH, Oil pressure
PCBOARD 152137 1 PCBORAD, Outrigger auto leveling
RST1 119629 1 RESISTOR, 2.7 kohm
S1 119726 1 SWITCH, Main power disconnect
S2 102853 1 BLOCK, N.O. contact (Up/down)
S3 - 1 SWITCH ASSEMBLY (Lift/Drive low/Drive)
137793 1 • HEAD, Switch selector (3-Way)
137788 1 • SWITCH ASSEMBLY (Base)
137783 3 • • BLOCK, N.C. Contact
137782 4 • • BLOCK, N.O. Contact
137781 1 • • LATCH
S4 - 1 SWITCH ASSEMBLY (Emergency stop)
137795 1 • SWITCH HEAD, Emergency Stop (Red)
137790 1 • SWITCH ASSEMBLY (Base)
137785 1 • • SWITCH, LED block (Red)
137783 2 • • BLOCK, N.C. Contact
137781 1 • • LATCH
S6 137790 1 SWITCH BASE ASSEMBLY (NC/LED, Red) (Base controls)
137795 1 SWITCH ASSEMBLY (Emergency stop)
S7 159109 1 CONTROLLER ASSEMBLY (Drive/steer)
S7-1 122869 1 • SWITCH W/ACTUATOR, 2nd Speed
S7-2 122877 1 • SWITCH, Right steer
S7-3 122877 1 • SWITCH, Left steer
S7-4 122869 1 • SWITCH W/ACTUATOR, Reverse drive
S7-5 122869 1 • SWITCH W/ACTUATOR, Forward drive
S7-6 122869 1 • SWITCH W/ACTUATOR, 3rd Speed
S7-7 122872 1 • SWITCH, Joystick enable
S8 - 1 SWITCH ASSEMBLY (Horn)
147058 1 • SWITCH HEAD, Push button (Black)
147054 1 • • BLOCK, N.O. Spring contact
S9A 102853 1 SWITCH, Outrigger Enable
S9B 127132 1 SWITCH, Outrigger Enable
S910 133762 1 BLOCK, N.O. Contact (Platform/Idle/Base) (Base controls)
