50
SJ6826RT, SJ6832RT
213560ABA
Section 3 – System Component Identication and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Qty. Description
S14 1 SWITCH ASSEMBLY (Low/High throttle select)
137794 1 • HEAD, Switch Selector (2-Way)
137786 1 • SWITCH ASSEMBLY (Base)
137782 1 • • BLOCK, N.O. Spring contact
137781 1 • • LATCH
S15 - 1 SWITCH ASSEMBLY (Start)
137792 1 • SWITCH HEAD, Push button (Black)
137786 1 • SWITCH ASSEMBLY (Base)
137782 1 • • BLOCK, N.O. Spring contact
137781 1 • • LATCH
S20 102853 1 SWITCH, Toggle (Front left outrigger up/down)
S20A 127132 1 SWITCH, Front left outrigger rocker
S21 102583 1 SWITCH, Toggle (Front right outrigger up/down)
S21A 127132 1 SWITCH, Front right outrigger rocker
S22 102853 1 SWITCH, Toggle (Rear right outrigger up/down)
S22A 127132 1 SWITCH, Rear right outrigger rocker
S23 102853 1 SWITCH, Toggle (Rear left outrigger up/down)
S23A 127132 1 SWITCH, Rear left outrigger rocker
S24 102853 1 SWITCH, Auto-level outrigger
S31 102692 1 SWITCH, Engine glow plug
S32 102692 1 SWITCH, Engine start push button
S33 115747 1 SWITCH, Fuel select
TPS1 113400 1 SWITCH, Engine temperature
TS1 146661 1 TILT SWITCH (KC Only)
TT 195940 1 HOUR METER
2H-13 103613 1 COIL, 12 Volt (Lowering valve)
2H-13-1 103613 1 COIL, 12 Volt (Lower lift cylinder holding valve)
2H-13-2 103613 1 COIL, 12 Volt (Upper lift cylinder holding valve)
2H-17A 106272 1 COIL, 12 Volt (Large pump dump valve)
2H-17C 106272 1 COIL, 12 Volt (Holding outrigger valve)
2H-18B 103613 1 COIL, 12 Volt (Small pump dump valve)
2H-86D 103613 1 COIL, 12 Volt (Hydraulic generator)
2P-50-1 125793 1 SOLENOID, Propane lock off valve, vaporizer (Kubota Dual Fuel Engine)
3H-14A 106272 1 COIL, 12 Volt (Lift valve)
3H-30 103613 1 COIL, 12 Volt (Brake valve)
4H-15A 128321 1 COIL, 12 Volt (Reverse drive valve)
4H-15B 128321 1 COIL, 12 Volt (Parallel reverse drive valve)
4H-16A 128321 1 COIL, 12 Volt (Forward drive valve)
4H-16B 128321 1 COIL, 12 Volt (Parallel forward drive valve)
4H-20A 137513 1 COIL 12 Volt (Series/Parallel drive)
4H-23 128321 1 COIL, 12 Volt (Right steer valve)
