94
SJ6826RT, SJ6832RT
213560ABA
Section 4 – Troubleshooting Information Electrical System
6. Defective Lift/Off/Drive Select switch S3.
Check continuity between wire #8A and wire #8B on
switch.
Replace if defective.
7. Defective or loose wire #8B from Lift/Off/Drive Select
switch S3 to Joystick S7 Steer Common P1-5.
Check continuity. Replace if defective.
8. Defective Joystick S7.
Operate Joystick. Check Steer direction switches S7-2
and S7-3.
Check for output to wire #A from Rev/Dn direction P1-6.
Check for output to wire #B from Fwd/Up direction P1-4.
Check for output to wire #23 from Steer Right P1-3.
Check for output to wire #24 from Steer Left P1-1.
Replace if defective.
9. Defective Lift/Off/Drive Select switch S3.
Check continuity between wire #A and wire #15 on
switch when Drive selected.
Check continuity between wire #B and wire #16 on
switch when Drive selected.
Replace switch if defective.
10. Loose or broken wire #15 from Lift/Off/Drive Select
switch S3 to Reverse Relay 15CR.
Check continuity. Replace if defective.
11. Loose or broken wire #02 from Reverse Relay 15CR to
Base terminal block TS-1.
Check continuity. Replace if defective.
12. Defective Reverse Relay 15CR. Check Relay. Replace if defective.
13. Loose or broken wire #15 from Reverse Relay 15CR to
Control Module CM1 pin #P2-8.
Check continuity. Replace if defective.
14. Loose or broken wire #16 from Lift/Off/Drive Select
switch S3 to Forward Relay 16CR.
Check continuity. Replace if defective.
15. Loose or broken wire #02 from Forward Relay 16CR to
Base terminal block TS-1.
Check continuity. Replace if defective.
16. Defective Forward Relay 16CR. Check Relay. Replace if defective.
17. Loose or broken wire #16 from Forward Relay 16CR to
Control Module CM1 pin #P2-7.
Check continuity. Replace if defective.
18. Loose or broken wire #10A from Base terminal block
TS-1 to Tilt Override/High Drive Cutout switch LS5.
Check continuity. Replace if defective.
