Weight and payload
Item Rear wheel drive vehicles
All wheel drive
vehicles
Kerb weight 1780 kg 1800 kg 1900 kg
Maximum laden
mass - total
2205 kg 2270 kg 2370 kg
Maximum laden
mass - front
956 kg 951 kg 1052 kg
Maximum laden
mass - rear
1249 kg 1319 kg 1318 kg
Maximum axle load
- front
1100 kg
Maximum axle load
- rear
1350 kg
aaa
Battery specifications
Besides state of charge and ambient tem-
perature, charging capacity also deter-
mines the charge time. The charging
capacity depends on the supply voltage,
the current intensity and the type of
power supply.
High voltage battery specifications
Item
Specification 1 Specification 2
Rated voltage
392 V 380 V
Rated capacity
169 A·h 130.5 A·h
Number of cores 107 120
Weight (without coolant) 390 kg 409.5 kg
aaa
12 V battery specifications
Item
Specification
Rated voltage
12 V
Rated capacity
50 A·h
aaa
Technical data 195
