E-motor specifications
Item
E-motor specifications
TZ220XSA01
TZ220XSA02
TZ180XSB01
Peak power
200 kW 115 kW
Maximum rotation speed
16500 RPM 16000 RPM
Peak torque
343 N·m 200 N·m
Rated power 75 kW 41 kW
Rated rotation speed 5345 RPM 4950 RPM
Rated torque 134 N·m 80 N·m
Rated voltage 400 V
aaa
Brake system specifications
Brake parameters
Item
Specification
Brake fluid DOT4
Brake pedal full travel
119 mm
Brake pedal free travel
2 - 8 mm
Replace the brake fluid regularly to guarantee the efficiency of the brake sys-
tem. It is recommended to have the brake fluid replaced at a smart Authorized
Service Partner.
aaa
Reasonable service range of the brake friction sets
Item
Specification
Front wheel Rear wheel
Standard thickness of the
brake disc
Rear wheel drive: 28 mm
20 mm
All wheel drive: 30 mm
196 Technical data
