Enable/disable air conditioning.
Enable/disable the maximum air
conditioning.
Enable/disable the climate control
AUTO mode (→ Page 85).
Enable/disable the climate control
ECO mode.
Set the air flow direction toward the
windscreen.
Set the air flow direction toward the
face.
Set the air flow direction toward the
foot.
Turning on/off the climate control (→
Page 85).
Switch the air circulation between in-
ternal/automatic/external.
Open the setting interface (→ Page
86).
Air vents
WARNING Risk of burns or frostbite
due to insufficient distance from the
air outlet
The air outlet may blow out overheated
or freezing air.
This may cause burns or frostbite to
people near the air outlet.
► Make sure that the occupants inside
keep a sufficient distance from the
air outlets.
► If necessary, guide the air flow to
other areas in the vehicle.
To make sure that fresh air enters the ve-
hicle through the air outlet, observe the
following:
● Make sure that the air outlet and venti-
lation grille inside the vehicle are
unimpeded.
● Make sure the air inlet is free of dirt
such as ice, snow and leaves.
Adjusting the front air outlet
1. Adjusting the air outlets on the driver
side: move the sliders
up, down, left
and right to adjust the air outlet direc-
tion. Turn the sliders
toward the
sides of the driver seat to the maximum
position to close the air outlets.
2. Adjusting the air outlets on the passen-
ger side: move the sliders
up, down,
left and right to adjust the air outlet di-
rection. Turn the sliders
toward the
sides of the passenger seat to the maxi-
mum position to close the air outlets.
Adjusting the rear air outlet
1. Adjusting the rear air outlet: move the
sliders
up, down, left and right to ad-
just air outlet direction. Turn the sliders
downward to the maximum position
to close the air outlets.
Climate control system 87
