If the towing mode cannot be acti-
vated or the centre display cannot
be accessed, the vehicle can be
loaded to the approved transporter
using tow brackets/small wheels/as-
sist wheels. Be sure to check the
manufacturer's specifications and
recommended load capacity before
using tow brackets/small wheels/as-
sist wheels.
Deactivating the towing mode
The towing mode is deactivated when one
of the following conditions is met:
1. The vehicle is shifted to park
and
locked from outside.
2. The vehicle is shifted to drive
or re-
verse
.
Fitting the tow bar
Fitting the front tow bar
1. Open the bonnet (→ Page 177).
2. Pull the front luggage compartment
cover handle
upward to open the
cover.
3. Take out the tow bar from the tool
kit in the front luggage compartment.
4. Remove the front tow bar cover .
5. Screw the tow bar in and tighten it.
6. After use, return the tow bar and front
tow bar cover to their original positions.
Fitting the rear tow bar
Type 1
1. Open the bonnet (→ Page 177).
2. Open the front luggage compartment
cover.
3. Take out the tow bar from the tool kit in
the front luggage compartment.
4. Press the lower point of the triangular
indicator
inward to remove the tow
bar cover
.
168 Breakdown assistance
