Use 2 rows of bars
tick box
Tick to enable the use of a second row of audio meter bars. When
ticked the first row of bars is displayed in the upper part of the tile and
the second row is displayed at the lower part of the tile.
When unticked only one row of audio meter bars is displayed.
Audio sources
Sets the source to display in each of the 16 bars of the meter. These
are configured in pairs. Set to None to turn a pair off, or select
Embedded or External audio pair as the source.
Audio Format
Sets the audio format for each audio source pair. Select from; Auto,
PCM and multiple Dolby E source types. Dolby E available for
MV-VIP3D cards only.
2nd row tick boxes
Tick to display the audio pair in the second row of audio meter bars.
This option only available if the Use 2 rows of bars tick box is ticked.
Position
Sets the vertical and horizontal position of the meter within the
window.
Setting examples:
• To position the top of the audio meter bars at the top of the tile
set to 0
• To position the middle of audio meter bars on the horizontal
centre line of the tile set to 50
• To position the bottom of audio meter bars at the bottom of
the tile set to 100
If the Use 2 rows of bars tick box is ticked the vertical and horizontal
slider settings are used for both meters.
Size
Sets the vertical and horizontal size of the meter within the window.
If the Use 2 rows of bars tick box is ticked the vertical and horizontal
slider settings are used for both meters.
Bar Colours:
Selects bar to which the color of the over, upper and lower range
applies, see section 4.4 for details on setting the levels at which the
colors change.
Over
Sets the over range color for the bar selected in the Bar Colours
control.
Upper
Sets the upper range color for the bar selected in the Bar Colours
control.
Lower
Sets the lower range color for the bar selected in the Bar Colours
control.
Wrong format
Not applicable if Audio Format is set to Auto.
Sets the wrong format color for the bar selected in the Bar Colours
control.
Labels
Sets the display of the bar labels to either an enumerated format, or
the labels as entered for the respective channels, or off.
Colour Sets the color of the bar labels.
Show Alarm
Indicators
Enables the alarm indicators at the top of the bars.
Transparent on
Video
Enables the transparency of the meter bars when they are on the
in-picture area.
Transparency Level
Sets the transparency of the audio bars when they are on the
in-picture area.
Table 35. Edit Object - Properties - Audio Tab.
