SN32F260 Series
32-Bit Cortex-M0 Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 127 Version 1.5
13.1 SN-LINK-V3.0
SN-LINK-V3.0 is a high speed emulator for SONiX 32-bit MCU. It debugs and programs
based on SWD protocol. In addition to debugger functions, the SN-LINK-V3.0 also may
be used as a programmer to load firmware from PC to MCU for engineering production,
even mass production.
SN-LINK-V3.0 communicates with SONiX 32-bit MCU through SWD interface. The pin
definition of the Modular cable is as following:
