SN32F260 Series
32-Bit Cortex-M0 Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 70 Version 1.5
6.7.9 CT16Bn Match Control register 3 (CT16Bn_MCTRL3) (n=1)
Address Offset: 0x1C
Bit
Name
Description
Attribute
Reset
31:12
Reserved
R
0
11
MR23STOP
Stop MR23: TC and PC will stop and CEN bit will be cleared if MR23
matches TC..
0: Disable
1: Enable.
R/W
0
10
MR23RST
Enable reset TC when MR23 matches TC.
0: Disable.
1: Enable.
R/W
0
9
MR23IE
Enable generating an interrupt based on CM[2:0] when MR23 matches the
value in the TC.
0: Disable.
1: Enable.
R/W
0
8
MR22STOP
Stop MR22: TC and PC will stop and CEN bit will be cleared if MR22
matches TC.
0: Disable.
1: Enable.
R/W
0
7
MR22RST
Enable reset TC when MR22 matches TC.
0: Disable.
1: Enable.
R/W
0
6
MR22IE
Enable generating an interrupt based on CM[2:0] when MR22 matches the
value in the TC.
0: Disable.
1: Enable.
R/W
0
5
MR21STOP
Stop MR21: TC and PC will stop and CEN bit will be cleared if MR21
matches TC.
0: Disable.
1: Enable.
R/W
0
4
MR21RST
Enable reset TC when MR21 matches TC.
0: Disable.
1: Enable.
R/W
0
3
MR21IE
Enable generating an interrupt based on CM[2:0] when MR21 matches the
value in the TC.
0: Disable.
1: Enable.
R/W
0
2:0
Reserved
R
0
